Hoarding & site fencing
Water-Filled Barrier
Water-ballasted plastic units that interconnect with each other for road works, lane closure, traffic management and event separation — 8–9 kg empty and 100 kg once filled, with a rotomoulded imported PE type also available.
- Product category
- Hoarding & site fencing — plastic water-ballast barrier in two types: blow-moulded tall barrier and rotomoulded imported PE barrier
- Brand
- HONGYING GUARDRAIL
- Manufacturer
- Hubei Hongying Guardrail Co., Ltd. — Jiangxia District, Wuhan, Hubei, China
- Project service
- Made to the project specification: drawing, standard, quantity and destination port
How to select
Fix the type first — the blow-moulded tall barrier or the rotomoulded imported PE barrier — then the height you need on the tall unit, the body colour and the length of run the units have to close. Those answers settle whether the units interconnect at corners and ends, the moulding, the unit size and how the empty units nest and ship.
A water-filled barrier is a barrier whose weight arrives with the job rather than on the truck: the tall blow-moulded unit is 8–9 kg to lift and 100 kg once it is filled, so what two people can position by hand then resists being pushed, leaned on or blown over. It is carried empty, filled on site and emptied again when the works move on — which is why it suits road works, lane closures and diversions, event separation and crowd lines, and separating a works area from live traffic.
Photographs below show the product family; the specification on this page is the manufacturer's published figure and is quoted unchanged.
01 · Product overview
What the water-filled barrier is made of
The published figures are a tall blow-moulded unit 102 cm long, 183 cm high (customisable) and 400 mm wide, 8–9 kg net and 100 kg filled with water, rated from −40 °C to +60 °C with a service life of more than two years as stated by the manufacturer, alongside a rotomoulded imported PE type whose moulding, unit size and price are confirmed per order.
The idea behind a water-filled barrier is that the weight arrives with the job rather than on the truck. A unit is 8–9 kg to lift and 100 kg once it is filled, so what two people can position by hand then resists being pushed, leaned on or blown over. It is carried empty, filled on site and emptied again when the works move on — which is why it suits road works, lane closures and diversions, event separation and crowd lines, and separating a works area from live traffic.
The tall barrier is blow-moulded in one hollow piece: 102 cm long, 183 cm high and 400 mm wide. The height is quoted as customisable, so tell us the figure you need and we confirm it on the order drawing. Units connect to one another, which is what turns single barriers into a continuous separation line, and the body is emerald blue or red with other colours supplied to requirement. The published weather range is −40 °C to +60 °C, and the manufacturer states a service life of more than two years, together with resistance to wind force of grade 7–8.
Where moulded polyethylene is preferred to blow-moulded material, the rotomoulded barrier is made from imported PE. No dimensions, weight or price are published for that type, so the moulding, the unit size and the price are confirmed per order from the quantity and the run length you need.
One point of wording matters here. The manufacturer states that the technical indices meet the relevant domestic standards; that is the manufacturer's claim for its product and not a certificate or approval held by us. Tell us the standard your project follows and we will confirm in writing what documentation we can supply.
Units in this family are quoted together: crowd-control barrier for queuing, events and pedestrian separation, and perforated hoarding where the boundary has to be closed to view rather than only to movement.
- Type 1Blow-moulded tall barrier, one hollow piece
- Length102 cm
- Height183 cm (customisable)
- Width400 mm
- Weight8–9 kg net; 100 kg filled with water
- Weather resistance−40 °C to +60 °C
- Service lifeMore than two years, as stated by the manufacturer
- Type 2Rotomoulded barrier, imported PE — figures per order
Pictured: the emerald blue tall barrier standing as a road and site separation line, two units connected end to end as a continuous run, and the barrier used with a highway crash barrel at a road works separation point.
02 · Technical specification
Water-Filled Barrier — specification
The figures below are the specification published for this product and are quoted unchanged: they are the numbers a quotation and a shop drawing are built on. Where a row says made to the project specification, send the drawing or the standard you follow and it is confirmed in writing.
| Product / model reference | Water-filled barrier — plastic water ballast barrier in two types: blow-moulded tall barrier and rotomoulded imported PE barrier. Quoted against your requirement; no catalogue model number is issued until the requirement is agreed. |
|---|---|
| Type 1 — tall water barrier (blow-moulded) | Blow-moulded in one hollow piece. Body colour emerald blue or red; other colours can be supplied to requirement. Units interconnect with each other. Withstands wind force of grade 7–8. |
| Length L (tall water barrier) | 102 cm |
| Height H (tall water barrier) | 183 cm (customisable) |
| Width W (tall water barrier) | 400 mm |
| Net weight (tall water barrier) | 8–9 kg |
| Weight when filled with water (tall water barrier) | 100 kg |
| Weather resistance (tall water barrier) | −40 °C to +60 °C |
| Service life (tall water barrier) | More than two years, as stated by the manufacturer. |
| Connection (tall water barrier) | Units interconnect with each other. |
| Colour (tall water barrier) | Body in emerald blue or red; other colours can be supplied to requirement. |
| Process (tall water barrier) | Blow-moulded in one hollow piece; withstands wind force of grade 7–8. The manufacturer states that the technical indices meet the relevant domestic standards. That statement is the manufacturer's claim for the product and is not a certificate or approval held by us; buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply. |
| Type 2 — rotomoulded water barrier | Material: imported PE. The manufacturer publishes no dimensions, weight or price for this type — send us the quantity and the run length you need and we confirm the moulding, the unit size and the price for the order. |
| Packing, price and delivery | |
| Packing | Empty units nest for shipping, which is what keeps a container load of barriers compact; cartons, pallets and the exact packing method are confirmed per specification with the loading plan. |
| Price | Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP |
| MOQ | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Loading | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Lead time | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Documentation | Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply. |
On a narrow screen the table scrolls sideways; every row stays readable in full.
03 · Features
Why the water-filled barrier is specified
- Use: road and site separation, road works, lane closure and diversion, event separation and crowd lines.
- Tall barrier dimensions: 102 cm long, 183 cm high (customisable), 400 mm wide.
- Weight: 8–9 kg net and 100 kg once filled with water — ballast carried as water, not as steel or concrete.
- Weather resistance: −40 °C to +60 °C; the manufacturer states a service life of more than two years.
- Connection: units interconnect with each other to form a continuous run.
- Colour: body in emerald blue or red; other colours can be supplied to requirement.
- Process: blow-moulded in one hollow piece; withstands wind force of grade 7–8.
- Rotomoulded type: moulded from imported PE; dimensions, weight and price confirmed per order.
04 · Made to your drawing
Made to the project specification
Send us the drawing or the standard you follow and we confirm in writing what we can supply against it. For a water-filled barrier order, that means the type, the height if it is the customisable tall unit, the colour, the quantity, the length of the run to be closed and whether the units have to interconnect at corners and ends.
What settles this specification
Which type, the colour, whether the units interconnect to close the run, the quantity per lane closure, and how the empty units are shipped and nested.
05 · Packing, price and delivery
How water-filled barriers are packed, priced and delivered
Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP. MOQ, loading plan and lead time are confirmed per specification — send the drawing, quantity and destination port and we reply within one business day.
| Packing | Empty units nest for shipping, which is what keeps a container load of barriers compact; cartons, pallets and the exact packing method are confirmed per specification with the loading plan. |
|---|---|
| Price | Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP |
| MOQ | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Loading | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Lead time | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Documentation | Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply. |
| Colour | RAL to sample — send the reference or a physical sample and we confirm the coating or the print on the shop drawing. |
Empty units nest for shipping, so one container load stays compact when it is unpacked on site.
06 · Questions buyers ask
Water-Filled Barrier — frequent questions
Every answer below repeats a figure or a term already published on this page; nothing is added to the specification here.
How is the water-filled barrier held down?
The ballast is water. A unit is 8–9 kg net to lift and 100 kg once it is filled with water, so it is carried empty, filled on site and emptied again when the works move on. The published weather range is −40 °C to +60 °C, and units interconnect with each other to form a continuous run.
What is made to my drawing?
The height of the tall barrier is quoted as customisable — 183 cm as published, 102 cm long and 400 mm wide — and the body is emerald blue or red with other colours supplied to requirement. The rotomoulded type is moulded from imported PE with no published dimensions, weight or price, so the moulding, the unit size and the price are confirmed per order from the quantity and the run length you need, together with whether the units have to interconnect at corners and ends.
Is there a catalogue model number or a published price?
No catalogue model number is issued until the requirement is agreed. Price is quoted per order — FOB Wuhan / Shanghai, CIF or DDP — and MOQ, loading plan and lead time are confirmed per specification; send the drawing, quantity and destination port and we reply within one business day.
What are the MOQ, the loading plan, the lead time and the packing?
MOQ, loading plan and lead time are confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. Empty units nest for shipping, which is what keeps a container load of barriers compact; cartons, pallets and the exact packing method are confirmed per specification with the loading plan.
What documents come with the order?
Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation tell us the standard, and it is confirmed in writing what can be supplied. The statement that the technical indices meet the relevant domestic standards is the manufacturer's claim for the product and is not a certificate or approval held by us.
