Municipal Hoarding
A post-and-panel works hoarding built on deep galvanised posts with a concealed inner post, a two-band panel face — 480 mm white over 400 mm grey — a 50 × 50 × 0.9 mm brace and a flange-plate base with expansion bolts.
- Product category
- Hoarding & site fencing — post-and-panel works hoarding
- Brand
- HONGYING GUARDRAIL
- Manufacturer
- Hubei Hongying Guardrail Co., Ltd. — Jiangxia District, Wuhan, Hubei, China
- Project service
- Made to the project specification: drawing, standard, quantity and destination port
How to select
Fix the run height, the total site length, the ground condition and the fixing first, then whether the face stays plain or takes printed panels. Those four answers settle the post spacing, the band heights, the finish and the packing.
This is the heavier of our post-and-panel hoardings. A deep galvanised post sits at each station, a concealed post carries the joint inside the panel line so the visible face stays flush, and the face itself is split into two horizontal bands. That combination is what gets specified where a works site stands directly against a public road, a footway or a residential frontage and the hoarding has to look orderly for the months the contract runs.
Photographs below show the product family; the specification on this page is the manufacturer's published figure and is quoted unchanged.
01 · Product overview
What the municipal hoarding is made of
The published sections are a 220×300×0.9 mm galvanised post, an 80×80×1.0 mm galvanised concealed post behind the face, a 480 mm white panel over a 400 mm grey panel, and a 50×50×0.9 mm square-tube brace propping the run from the works side.
The base is a flange plate with expansion bolts, so the hoarding is bolted to a concrete or paved surface rather than cast into it — and can be taken up again when the contract ends. Because the two bands are standard heights, the surface a contractor or a city authority gets is a quiet background for project signage, safety notices and printed graphics.
The panel face is deliberate and plain, and it is the reason this hoarding is often specified next to a powder-coated colour-steel hoarding: one closes a long frontage with a low-key two-band face, the other carries colour and a warning board along the base. Where the site needs air and light through the face instead, perforated hoarding is the usual alternative. Neither is a substitute for the other, and both are quoted from the same Wuhan workshop.
Run height and post spacing are not published as fixed figures: they follow the site and the wind exposure. Tell us the height, the site length, what the ground can accept as a fixing and whether the face stays plain or takes printed panels, and the post spacing, band heights, finish and packing are confirmed as one specification.
- Post220×300×0.9 mm galvanised tube
- Concealed post80×80×1.0 mm galvanised tube behind the face
- Panel480 mm white over 400 mm grey
- Brace50×50×0.9 mm square tube
- FittingsFlange plate and expansion bolts
- FinishGalvanised steel; panel face white and grey
- Run height and post spacingConfirmed on the order drawing
- UseClosing a city street, road, drainage or metro works site
Pictured: the two-band face, the concealed post at the panel joint and the brace and flange-plate node that hold the run against the works side.
02 · Technical specification
Municipal Hoarding — specification
The figures below are the specification published for this product and are quoted unchanged: they are the numbers a quotation and a shop drawing are built on. Where a row says made to the project specification, send the drawing or the standard you follow and it is confirmed in writing.
| Product / model reference | Municipal hoarding — galvanised post-and-panel works hoarding. Quoted against your requirement; no catalogue model number is issued until the requirement is agreed. |
|---|---|
| Post (立柱) | 220×300×0.9 mm galvanised tube. |
| Concealed post (暗柱) | 80×80×1.0 mm galvanised tube, set behind the panel face at the panel joint. |
| Panel (面板) | 480 mm white panel over 400 mm grey panel — a two-band face. |
| Brace (斜撑) | 50×50×0.9 mm square tube, propping the run from the works side. |
| Fittings (配件) | Flange plate and expansion bolts. |
| Run height and post spacing | Not published by the manufacturer as fixed figures. Tell us the height you need and the ground condition, and post spacing and brace positions are confirmed on the order drawing. |
| Finish and colours | Galvanised steel as published. The panel face is white and grey; printed or project-specific graphics are agreed per order. |
| Packing, price and delivery | |
| Packing | Panels, posts, concealed posts, braces and fittings are bundled by type for shipping; banding, pallets and the exact bundle layout are confirmed per specification with the loading plan. |
| Price | Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP |
| MOQ | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Loading | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Lead time | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Documentation | Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply. |
On a narrow screen the table scrolls sideways; every row stays readable in full.
03 · Features
Why this post-and-panel hoarding is specified
- Use: closing a city street, road, drainage or metro works site from the public; long frontages where the hoarding stays up for the contract.
- Post: 220×300×0.9 mm galvanised tube.
- Concealed post behind the face: 80×80×1.0 mm galvanised tube, set at the panel joint so the face stays flush.
- Panel face: 480 mm white panel over 400 mm grey panel — the common municipal two-band pattern.
- Brace: 50×50×0.9 mm square tube, propping the run from the works side.
- Fittings: flange plate and expansion bolts, so the hoarding is bolted down rather than cast in.
- Finish: galvanised steel as published; the panel face is white and grey, and a printed face is agreed per order.
- Run height and post spacing are confirmed on the order drawing against the site and the wind exposure.
04 · Made to your drawing
Made to the project specification
Send us the drawing or the standard you follow and we confirm in writing what we can supply against it. For a municipal hoarding, that means the run height, the total length, the ground condition and fixing, the wind exposure, the two band heights, the brace positions and whether the face stays white and grey or takes printed graphics.
What settles this specification
The height and length of the run, the ground condition, the wind exposure, the face — plain two-band or printed — and whether the hoarding is a one-contract installation or has to come down and go up again.
05 · Packing, price and delivery
How municipal hoarding is packed, priced and delivered
Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP. MOQ, loading plan and lead time are confirmed per specification — send the drawing, quantity and destination port and we reply within one business day.
| Packing | Panels, posts, concealed posts, braces and fittings are bundled by type for shipping; banding, pallets and the exact bundle layout are confirmed per specification with the loading plan. |
|---|---|
| Price | Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP |
| MOQ | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Loading | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Lead time | Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day. |
| Documentation | Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply. |
| Colour | RAL to sample — send the reference or a physical sample and we confirm the coating or the print on the shop drawing. |
Long sections are bundled by type, so one bundle is one kind of part when the container is unpacked on site.
06 · Questions buyers ask
Municipal hoarding — frequent questions
Every answer below repeats a figure or a term already published on this page; nothing is added to the specification here.
How is the municipal hoarding fixed down?
The published fitting is a flange plate with expansion bolts, so the hoarding is bolted to a concrete or paved surface rather than cast into it. The base condition and the exact fixing are confirmed against the site before the order drawing is issued.
Can the run be made to my drawing?
Yes. The listed sections are quoted unchanged, and the open items — run height, post spacing and brace positions — are made to the project specification. Send the drawing or the standard you follow and we confirm in writing what we can supply against it.
Is there a catalogue model number or a published price?
No catalogue model number is issued until the requirement is agreed. Price is quoted per order — FOB Wuhan / Shanghai, CIF or DDP — and MOQ, loading plan and lead time are confirmed per specification; send the drawing, quantity and destination port and we reply within one business day.
What documents come with the order?
Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation tell us the standard, and it is confirmed in writing what can be supplied.
Can the posts and panels be reused on the next contract?
The flange-plate base is bolted rather than cast in, so the hoarding can be taken up again when the contract ends. Whether the run is a one-contract installation or has to come down and go up again is one of the points that settles the specification, and it is taken into account in the packing.
