PVC Railing

Extruded PVC profile rails and vertical bars between posts — rails 36 × 56 mm, bars 20 × 46 mm and posts in 58 × 78, 88 × 88 or 121 × 121 mm, made from domestic virgin material.

Product category: Guardrails and railings — extruded PVC profile railing for green belts, lawns and community boundaries
Brand: HONGYING GUARDRAIL
Manufacturer: Hubei Hongying Guardrail Co., Ltd. — Jiangxia District, Wuhan, Hubei, China
Project service: Made to the project specification: drawing, standard, quantity and destination port

How to select

The post section settles most PVC railing orders: 58 × 78 mm (small) for short garden and lawn runs, 88 × 88 mm (medium) for the usual community and roadside boundary, and 121 × 121 mm (large) where the railing is taller, more exposed or has a longer span between posts. The colour is settled at the extrusion stage, so a colour reference or a sample is what sets it. Then the run in metres with its corners, ends and any gate, the height and the post spacing are cut to your drawing.

Get a quote Back to products

This is the railing for places where a steel fence would be the wrong answer. Around planted beds, lawns and green belts, along a roadside planting strip or on a community boundary, the railing only has to define an edge — so the colour is put into the extrusion itself rather than laid on top of it as a coating, and there is nothing to flake and nothing to repaint. The published profile sizes, the three post sections and the material are what a quotation is built on.

Photographs below show the product family; the specification on this page is the manufacturer's published figure and is quoted unchanged.

01 · Product overview

What the PVC railing is made of

The published figures are rails of 36 × 56 mm, vertical bars of 20 × 46 mm and posts in three sections — 58 × 78 mm (small), 88 × 88 mm (medium) and 121 × 121 mm (large) — all made from domestic virgin material and published in white, blue, red, green and others.

A PVC railing is the right fence in places where a steel one would be the wrong answer. Around planted beds, lawns and green belts, along a roadside planting strip or on a community boundary, the railing has to define an edge without turning the landscape into a compound, and the material does that quietly: the colour is in the extrusion rather than sitting on top of it as a coating, so there is nothing to flake and nothing to repaint.

The profile sizes are published. Rails are 36 × 56 mm and vertical bars are 20 × 46 mm, with posts in three sections — 58 × 78 mm (small), 88 × 88 mm (medium) and 121 × 121 mm (large). The post is usually how the railing is specified: the small section for short garden and lawn runs, the medium for the usual community and roadside boundary, and the large where the railing is taller, more exposed, or has a longer span between posts.

Material is domestic virgin material, meaning new resin rather than reground or recycled stock, and the published colours are white, blue, red, green and others. Because the colour runs through the section, it is settled at the extrusion stage, so a colour reference or sample is what sets the order.

No standard run length or height is published, so both are cut to your drawing: send the run in metres with its corners, ends and any gate, the height you want and the post spacing, and the rails, bars and posts are counted from those figures. For a boundary where impact or security is the issue, the zinc-steel perimeter railing and the road guardrail are the products to quote instead.

Rails36 × 56 mm
Vertical bars20 × 46 mm
Post options58 × 78 mm (small), 88 × 88 mm (medium), 121 × 121 mm (large)
MaterialDomestic virgin material
ColoursWhite, blue, red, green and others
Run lengthMade to the project specification
HeightMade to the project specification
Typical useGreen belts, lawns, planters, community boundaries

Pictured: the railing standing along a green belt beside a road, the same profile set along a lawn edge in a planted area, and the coloured extrusions on a residential boundary.

02 · Technical specification

PVC Railing — specification

The figures below are the specification published for this product and are quoted unchanged: they are the numbers a quotation and a shop drawing are built on. Where a row says made to the project specification, send the drawing or the standard you follow and it is confirmed in writing.

PVC Railing — specification, packing, price and delivery
Packing, price and delivery
Product / model reference	PVC railing (PVC 护栏) — profile railing for green belts, lawns, planters and community boundaries.
Rails	36 × 56 mm.
Vertical bars	20 × 46 mm.
Post options	58 × 78 mm (small); 88 × 88 mm (medium); 121 × 121 mm (large).
Colours	White, blue, red, green and others.
Material	Made from domestic virgin material.
Run length	Made to the project specification — send us the drawing or the standard you follow.
Height	Made to the project specification — send us the drawing or the standard you follow.
Post spacing and panel layout	Made to the project specification — send us the drawing or the standard you follow.
Post fixing	Made to the project specification — confirmed on the shop drawing.
Typical use	Green belts, lawns, planters, roadside planting strips, community and garden boundaries.
Not intended for	Vehicle impact or security duty — for those, the zinc-steel perimeter railing and the road guardrail are quoted instead.
Packing	Rails, bars, posts and fittings are bundled and palletised for container loading; the exact packing method is confirmed per specification with the loading plan.
Price	Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP
MOQ	Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.
Loading	Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.
Lead time	Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.
Documentation	Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply.

On a narrow screen the table scrolls sideways; every row stays readable in full.

03 · Features

Why this PVC railing is specified

Rails 36 × 56 mm; vertical bars 20 × 46 mm (manufacturer's published profile sizes).
Post options: 58 × 78 mm (small), 88 × 88 mm (medium) and 121 × 121 mm (large).
Colours: white, blue, red, green and others — the colour runs through the section rather than sitting on it.
Material: made from domestic virgin material.
Run length, height and panel layout: made to the project specification — send us the drawing or the standard you follow.
Post fixing: made to the project specification and confirmed on the shop drawing.
Typical use: green belts, lawns, planters, community and garden boundaries, roadside planting strips.
Not intended for vehicle impact or security duty; the zinc-steel perimeter railing and the road guardrail are quoted for those.

04 · Made to your drawing

Made to the project specification

Send us the drawing or the standard you follow and we confirm in writing what we can supply against it. For a PVC railing, that means the post section, the rail and bar profiles, the colour, the run in metres, the height, the post spacing and the post fixing, including any curves and changes of level.

Send the drawing Call 15071050608

What settles this specification

The post size, the colour and the run with its height and post spacing. The profile sizes are published, but no standard run or height is, so the railing is cut to your drawing.

05 · Packing, price and delivery

How PVC railing is packed, priced and delivered

Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP. MOQ, loading plan and lead time are confirmed per specification — send the drawing, quantity and destination port and we reply within one business day.

Packing, price and delivery
Packing	Rails, bars, posts and fittings are bundled and palletised for container loading; the exact packing method is confirmed per specification with the loading plan.
Price	Price: quoted per order — FOB Wuhan / Shanghai, CIF or DDP
MOQ	Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.
Loading	Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.
Lead time	Confirmed per specification — send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.
Documentation	Proforma invoice, commercial invoice, packing list and certificate of origin as required. Buyers who need CE / EN / ASTM documentation: tell us the standard and we will confirm in writing what we can supply.
Colour	RAL to sample — send the reference or a physical sample and we confirm the coating or the print on the shop drawing.

Long sections are bundled by type, so one bundle is one kind of part when the container is unpacked on site.

06 · Questions buyers ask

PVC Railing — frequent questions

Every answer below repeats a figure or a term already published on this page; nothing is added to the specification here.

Which post section do I need?

Posts are published in three sections: 58 × 78 mm (small), 88 × 88 mm (medium) and 121 × 121 mm (large). The small section is for short garden and lawn runs, the medium for the usual community and roadside boundary, and the large where the railing is taller, more exposed, or has a longer span between posts.

What is published and what is made to my drawing?

The profiles are published and quoted unchanged: rails 36 × 56 mm and vertical bars 20 × 46 mm. Run length, height, post spacing and panel layout are made to the project specification — send us the drawing or the standard you follow, with the run in metres and any curves and changes of level, and those figures are confirmed in writing.

How is the railing fixed down?

Post fixing is made to the project specification and is confirmed on the shop drawing. Send the drawing or the standard you follow and the fixing is confirmed in writing along with the rest of the specification.

Is there a catalogue model number or a published price?

Price is quoted per order — FOB Wuhan / Shanghai, CIF or DDP — and MOQ, loading plan and lead time are confirmed per specification. Send the drawing, quantity and destination port and we reply with MOQ, loading plan and lead time within one business day.

How is the railing packed, and what comes with the order?

Rails, bars, posts and fittings are bundled and palletised for container loading; the exact packing method is confirmed per specification with the loading plan. Documentation is a proforma invoice, commercial invoice, packing list and certificate of origin as required, and buyers who need CE / EN / ASTM documentation tell us the standard and it is confirmed in writing what we can supply.
